| Technicial Specifications | |
|---|---|
| ELECTRICAL INPUT | 380 / 400 V · 50 Hz · 3 Phase · 35.3 kW |
| SHEET WİDTH RANGE | 1200 mm · 1250 mm · 1500 mm |
| SHEET THİCKNESS RANGE | Galvanized Steel: 0.5 mm ? 1.2 mm (400 N/mm²) |
| Stainless Steel: 0.5 mm ? 0.8 mm | |
| PUNCH MODEL | TDF |
| SHEET WİDTH TOLERANCE | ± 0.5 mm |
| DİAGONAL TOLERANCE | ± 0.8 mm |
| SPEED | 6 m/min |
| PRİSMATİC DUCT SİZE | Minimum: 150 mm × 1700 mm |
| Maximum: 900 mm × 900 mm | |
| HYDRAULİC SYSTEM | 150 bar · 3 kW + 160 bar · 3 kW |
| L-TYPE DUCT DİMENSİONS | Minimum: 150 mm × 3550 mm |
| Maximum: 1800 mm × 1800 mm | |
| MACHİNE DİMENSİONS (L × W × H) | 15000 mm × 7000 mm × 1200 mm |
